True Industrial Rugged Tablet
OP F7
Worry free tablet that will surely give you peace of mind
- 10.1 inch Multi Touch Screen Monitor
- Water abnd Drop Proof Case IP67
- 9.7 inch Customer Display Optional
- Intel Processor Option J6412/Core i3/Core i5/i7
- RAM Capacity Option 8/16GB DD4 Memory
- Storage Option 256/512/1TB SSD
Technical Specifications
| Product Form | Form Factor | IP67 Rugged Tablet PC |
| Dimensions | 280x184x26.5mm | |
| Weight | 1.15KG | |
| Display | Screen Size | 10.0" |
| Screen Resolution | 800x1280 (IPS+HD+300ANSI) (Standard) | |
| Touch Module | G+G Multi-Touch (10 Points) | Battery | Type | Rechargable lithium polymer |
| Capacity | 5000mAh/7.6V | |
| Working Time | Over 5 hours (FHD local video display) | |
| Storage Options | 256GB / 500GB / 1TB SSD | |
| CPU | Type | Intel Gemini lake N4120 (Quad-Core) |
| Speed | 1.1GHz ~ 2.6GHz (N4120) | |
| GPU | Type | Intel UHD 600 Graphics |
| Memory | Capacity | 8GB LPDDR4 |
| Storage | eMMC | 128GB |
| SSD | Optional (Mini PCI-E slot) | |
| Camera | Front/Read | 2M |
| Speaker | Built-in | 8Ω/1W*2pcs with water proof |
| Microphoe | Built-in | Yes |
| G-sensor | Built-in | Yes |
| Wifi | WIFI Module: Intel AC3165 | WIFI 802.11ac/b/g/n/ 2.4G&5Ghz Dual-band |
| Bluetooth | BT Module: Intel AC3165 | Bluetooth4.2 |
| Ethernet Network | RJ-45 | 1000Mbps Gigabit Lan |
| Type | Details | Descriptions |
| Type-C | Type-C 3.1 | x1pc |
| USB Interface | USB3.0 | x2pc |
| SD / TF Card reader | TF Card reader | x1pc (up to 512GB) |
| SIM Card Slot | SIM Slot for 4G LTE | x1pc |
| Audio Jack | 3.5mm standard headphone+Microphone/td> | x1pc |
| HDMI | Micro HDMI 2.0 | x1pc (Output 4k@60fps UHD video) |
| COM Port | DB9 (RS232) | x1pc |
Download Resources
Access all the resources you need for your OP F7 POS system. Download manuals, drivers, and brochures to get the most out of your device.
