All-in-one POS Machine
AX90
Sleek and compact design but powerful machine that delivers unparalleled functionalities
- 11 inch Multi Touch Screen Monitor with 4.3 inch Second Display
- ABS Composite Plastic with Metal Base Stand
- Build-in 58mm Thermal Printer with 1D/2D Scanner and NFC Reader
- Intel Processor Option 6412/Core i3/Core i5/i7
- RAM Capacity Option 8/16GB DD4 Memory
- Storage Option 256/512/1TB SSD
Technical Specifications
| Model | AX90 |
| Processor Options | Intel Celeron J6412 / Core i3 / Core i5 / Core i7 |
| Mainboard | Intel Industrial Motherboard |
| Main Display | 15-inch 4:3 ratio (1024×768), 10-point capacitive touch |
| Memory Options | 8GB / 16GB DDR4 |
| Storage Options | 256GB / 500GB / 1TB SSD |
| Network Communication | 10/100/1000Mbps Ethernet |
| WiFi IEEE 802.11a/b/g/n/ac | |
| Operating Systems | Windows 8/10/11, Linux OS |
| Interfaces | COM×2, VGA×1, HDMI×1, USB 3.0×2, USB 2.0×4, LAN×1, DC×2 |
| Optional Features | Customer Display: VFD220 / 9.7-inch / 12-inch / 15-inch |
| Built-in: WiFi / Loudspeaker | |
| Reader: MSR / RFID / NFC / iButton | |
| Power Supply | 12V/5A |
| Color Options | Silver / Black |
| Material | Aluminum Alloy |
| Warranty | 1 to 3 years onsite |
| Certifications | ROHS / CE / FCC |
Download Resources
Access all the resources you need for your AX90 POS system. Download manuals, drivers, and brochures to get the most out of your device.
